75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

  • 1
  • 2
  • 3

Brand Name : Furious Motor

Model Number : 75141

Certification : CE

Place of Origin : China

MOQ : 1

Price : $449

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 3000 pcs per month

Delivery Time : 5-8 working days

Packaging Details : Carton witn protection (EPE)

Model : 75141

Dimension : 75mm * 141mm

KV : 100

Max. Thrust : 58KG

Max. Torque : 11.9N.m

Max. RPM : 5500

Suggested ESC : 14S 160A

Suggested Prop : PD-1

Max. Current : 120A

Max. Voltage : 55V

Max. Power : 6.8KW

Li - Po : 14S - 24S

Hall Sensor : Optional

Weight : 2KG

Application : Efoil, electric boat.

Contact Now

Intoroduction

Unleash the potential of your aquatic projects with our 75141 brushless motor propulsion system, a comprehensive solution engineered for maximum power. This system, centered around a high-thrust BLDC motor capable of generating up to 56kg of force, includes the DP-3 propeller, 14S 160A ESC, and DC-2 controller for seamless integration and optimal control.

Whether powering underwater thrusters, e-foils, electric surfboards, or underwater scooters, this system delivers the performance required for thrilling water-based adventures.

Tech Specs

Model 75141
Type Brushless DC motor
KV 100
Suggested ESC 14 S 160 A
Suggested Propeller PD-2
Max. Thrust 58 kg
Max. Torque 11.9 N·m
Max. RPM 5500
Li-Po 8 S ~ 14 S
Max. Voltage 57 V
Max. Current 120 A
Max. Power 6.8 kW
Motor Dimension 75 mm * 141 mm
Weight 2 kg
Application Electric surfboard, efoil, underwater thruster, electric boat

Details

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils

75KG Thrust Submersible Brushless Motor For Electric Surfboards And Foils
